DGIS-12s
DigiGel®
Description:
Simple gel documentation , capture gel image for DNA , RNA , protein etc. affordable price, easy setup.
Applications :
EtBr Gel , SYBR Green Gel , SYPRO Orange Gel , SYPRO Red Gel ,
SYPRO Ruby Gel , Commasie blue Gel , X-ray film , Colony plate ,
Western blot , TLC plate , Silver stain gel, Western blot membrane etc.
Specification :
1.High resolution 24,000,000 pixels
2.Sensitivity setting: ISO = 100-12000
3.Image capture: Color, B&W
4.Monitor: 7 inch display Gel image (HDMI)
5.Directly operation: don't need computer control, protect from EtBr contaminate
6.Image can be transfer to computer via cable or memory card transfer or wifi.
7.Long time exposure: 1/4000 second - 60 second.
8.Aperture range : maximum F4.0(W) / F6.0(T)
9.Reflective light source: 4W x 2 tubes / white light , (option) e.g. UV 365nm, 254nm, 306nm.
10.Manual zoom in , zoom out, focus.
11.Moveable dark hook for easy transfer from UVlight box to white light box.
12. Fit on any kind of UV transilluminator or blue light box (option: platform adapter) .
